Triple glazing
Ultra Low-E
52mm triple glazing achieving unprecedented thermal insulation of Ug 0.5 W/m²K. Laminated and tempered glass, with SWISSPACER Ultimate warm-edge spacer and heat-soaked edges. Passivhaus certified.
0.5
W/m²K (Ug)
40 dB
Sound insulation
52mm
Thickness
Technical specifications
Thermal transmittance (Ug)
0.5 W/m²K
Passivhaus certified (PHI)
Package thickness
52 mm
Optimized triple glazing
Sound insulation
40 dB
Superior acoustic comfort
Glass type
Laminated + Tempered
Heat-soaked and tempered
Spacer
SWISSPACER Ultimate
PHI-certified warm-edge
Fill gas
Argon / Krypton
Inert insulating gas
How does Triple Ultra Low-E work?
6 layers of thermal and acoustic protection, each with a precise role.
Outer glass
Tempered, with Ultra Low-E coating on the inner face. Reflects thermal radiation back to the exterior.
Chamber 1 - Argon
16-18mm space filled with argon, which insulates 3x better than air.
Middle glass
Laminated and tempered glass with Low-E coating on both faces. Central thermal barrier.
Chamber 2 - Argon
The second argon chamber completes the insulation. Heat-soaked edges for maximum durability.
Inner glass
Tempered glass with Ultra Low-E coating on the outer face. Reflects interior heat back into the house.
SWISSPACER Ultimate
PHI-certified warm-edge spacer that eliminates the thermal bridge at the glass edge.
Triple Ultra Low-E vs standard glazing
| Feature | Triple Ultra Low-E | Standard Triple | Double Glazing |
|---|---|---|---|
| Ug (W/m²K) | 0.5 | 0.7 - 0.8 | 1.1 - 1.4 |
| Glass panes | 3 | 3 | 2 |
| Low-E coating | Ultra Low-E (3 layers) | Low-E (1-2 layers) | Low-E (1 layer) |
| Spacer | SWISSPACER warm-edge | Standard aluminium | Standard aluminium |
| Sound insulation | 40 dB | 33 - 36 dB | 28 - 32 dB |
| Passivhaus certification | ✓ Yes | ✗ No | ✗ No |
